2009 Harley Davidson Nightster 1200xl

2009 Harley Davidson Nightster 1200xl

Harley Davidson XL 1200N Nightster

Make Model	Harley Davidson XL 1200N Nightster
Year	2009 - 10
Engine	Fur stroke, 45� V-Twin Evolution� Valve Train Pushrod-operated, OHV, 2 valves per cylinder
Capacity	1199 cc / 73.2 cu-in
Bore x Stroke	88.8 x 96.8 mm
Cooling System	Air cooled
Compression Ratio	9.7:1
Lubrication	Dry-sump
Induction	Electronic Sequential Port Fuel Injection (ESPFI)
Ignition	Digital CDI
Starting	Electric
Max Torque	107.3 Nm / 79 lb-ft @ 4000 rpm
Clutch	Wet 9-plate
Transmission	5 Speed
Final Drive	Belt
Primary Drive	Chain, 57/38 ratio
Gear Ratio	1st 9.315 2nd 6.653 3rd 4.948 4th 4.102 5th 3.517
Frame	Mild steel, tubular frame, circular sections, cast junctions Swingarm Mild steel rectangular tube sections, stamped junctions, MIG welded
Front Suspension	39mm Forks
Rear Suspension	Coil-over, dual-adjustable preload
Front Brakes	Single 292mm disc 2 piston calipers
Rear Brakes	Single 292mm disc 1 piston caliper
Front Tyre	100/90B19 57H
Rear Tyre	150/80B16 77H
Rake	30.5�
Trail	117 mm / 4.8 in
Dimensions	Length 2179 mm / 85.8 in
Wheelbase	1519 mm / 59.8 in
Seat Height	Laden  653 mm  /  25.7 in Unladen 683 mm  /  26.9 in
Ground Clearance	100 mm / 4.7 in
Dry Weight	252 kg / 335 lbs
Wet Weight	301 kg /665 lbs
Fuel Capacity	12.5 Litres / 3.3 US gal

Ready to wheel its way through the alleyways and backstreets, the Nightster takes the Sportster legend in a dark direction with dead-on, rat-rod styling. Black finishes cover wheel rims and hubs, forks and handlebar, hand and foot controls. Old school style fork gaiters and a bullet-hole belt guard emphasize the original look. A low suspension puts the rider at seat height of just 25.3 inches. The new smaller front and rear fenders show more of the black laced steel wheels. The soulful 1200 Evolution engine growls through a Chrome Slash-Cut Staggered exhaust.

Rubber-mounted XL Evolution 1200cc engine
Medium Gray powder-coated engine with polished covers
Black laced steel wheels, 19-inch front / 16-inch rear
New low profile front fender
Black low-rise handlebar
Sportster Classic solo seat
Chrome Slash Cut Staggered Shorty Dual exhaust
Black mid-mount foot controls
Lowest-Profile rear shocks
Lowest-Profile front forks
Classic 3.3-gallon fuel tank
Black front forks with gaiters
Bullet hole belt guard and front fender supports
Side-mount license plate holder
Combination rear brake/tail/turn lights
Lowered front and rear suspension
Optional Smart Security System

Review

Have you had your fill of virtually everything under the sun being called "old school" (or old skool, oldschool and oldskool; take your pick)? I know I have. What was once a genuine urban turn of phrase suddenly finds its way into everyday language, and its trendy tone is spewed casually from grade schoolers to grannies. Thanks for nothing, mindless advertising agencies!

Now that you know how I feel about that, let me share a great piece of slogan: "An iron fist in a soft-bellied world." Huzzah! Bring that copywriter a beer - a Harley-branded beer.

Clearly meant to get your attention and anchor your emotions with that zinger, Harley-Davidson wants to let you know that they've carved out another bike from their 1,200cc Sporty platform, and slammed it with tough looks and attitude. The XL1200N Sportster Nightster is low, bobbed and blacked-out. With a gut full of torque, low seat-height, minimalist features and subtle colors, this Harley really had me thinking it was one that I would gladly have in my garage. It even turned the head of a non-biker female friend.

The Nightster has the same 73 cubic-inch, rubber-mounted, fuel-injected, air-cooled Evolution five-speed Twin with a compression ratio of 9.7 and churning out a claimed pavement-ripping 79 ft-lbs. of torque that all the other 1200 Sporties have. But the mill in this bike comes in a "rawboned finish." Rawboned? Just know that it (like most other components on the bike) is black. That black simplicity finds its way across much of the rest of the bike. The low-rise bars, clutch and brake levers, headlight housing, speedometer, mirrors, turn/stop lights, steel-spoked wheels, and drilled-out belt-drive guard all come in a slick black finish. Heck, even the front fender clamps are black.

The Nightster sets itself apart stylistically and functionally from the other Sportsters beyond all that black.

About the only thing that hearkens to chrome cruiser traditions is the staggered exhaust with slash-cut mufflers. Slowing the Nightster is the job of a single disc brake up front. Only one rotor means you can see the jewel-like pattern that the spoke heads create in the wide-flange black hub of the 19-inch front wheel. The rear is a 16-inch spoked job that matches up perfectly with to the front. Gone is the taillight. No, really, there's no taillight. However, there are two red LED turn signals that pull double duty as indicators, and (have you guessed it?) brake light. It just plain looks cool. Both fenders are chopped to reveal more rubber with the front looking very flat track-ish in profile. In an effort to go a little retro, fork gaiters cover up the fork stanchions. A bobber-inspired side-mount license plate not only cleans up the look of the rear fender, it also has a pivoting mechanism that allows the plate to be turned from its rear-facing position to one 90 degrees rotated, facing outward to the side. (Hmm, wouldn't that make it difficult to see by, say, the police or a toll-booth camera... - Ed.)

A number of paint options are available. The black on black looks particularly menacing, but our test unit came in two-tone Suede Blue Pearl and Vivid Black. That color combo may not strike fear in the hearts of hardened criminals or card-carrying members of the N.O.W., but once I saw it up close I was surprised at just how well the two colors went together. It looks great and takes nothing from the devil-may-care attitude the overall theme hopes to inspire.

It's hard not to be enthused about riding such a good looking, minimalist machine.

Once the fuel-injected powerplant thundered to life, I forgot for a moment about the cramped cockpit and started blipping the throttle. Intoxicated with a sense of self-entitled badass-ness, I twisted the throttle time and again to hear the exhaust and feel the torque reaction of the engine. Every stoplight brought another opportunity.

All that cage-annoying throttle pumping could only lead to one thing: Pull in the light clutch (reduced in effort on all '07 Sportsters), nudge the clean-shifting tranny into first, keep the revs up...red...green...go! Slam the throttle open, dump the clutch and hold on as the Torquinator lays down a long blackie worthy of bikes with much more horsepower.

Ride the bike long enough to build some heat in the rear tire and you can get a respectable-for-a-cruiser wheelie out of the Nightster from a dead stop. This ridiculous fun only serves as more fuel for the type of riding this bike seemed to beg from me. I couldn't help but keep the throttle turned up, the trouble-free fueling blasting me through traffic making me an easy target for law enforcement.

After I left the confines of the city behind via the sprawling L.A. freeway system, I quickly discovered that the Nightster is no distance machine. In keeping with the bobber theme, the bike has traditional twin coil-over shocks that are adjustable only for preload. The ride is tolerable, but the pitiful 2.4 inches of rear suspension travel will leave your posterior begging for more stops along the way.

Searching out one of my favorite canyon roads I was reminded of one more key area where the XL1200N differs: ground clearance. With a mere 3.9 inches of clearance, hard parts will suffer. Thankfully the footpegs are graced with extra-long feelers. The fireworks display trailing behind is impressive, or so I'm told.

I suspected (before scrutinizing the spec chart) that perhaps this Sportster had a more aggressive rake and trail combo or shorter wheelbase than its brothers. Not so. In fact, at 60 inches, the wheelbase is a fraction of an inch longer than a number of the other XL1200 models.

What I did learn was that Mr. Nightster requires minimal effort to turn. How so with a longer wheelbase?

Part of the reason is that this price-conscious Harley weighs substantially less than the other 1200 Sporties. At 545 pounds dry (claimed) it bests the Roadster model by a full 20 pounds, according to Harley-supplied numbers. This spec sheet factoid corroborated what my senses were telling me about the Nightster's handling in the twists and turns.

The single front disc brake, as opposed to the dual rotors on the 1200R, reduces rotational mass for lighter steering.

Eventually I had to give up on my aches-and-pains-be-damned mentality as the tight ergos had my knees aching. It was time to reel in my enthusiasm for the day. It's hard not to be enthused about riding such a good looking, minimalist machine. If you're a woman, (this isn't sexist, many women are drawn to Sportsters), a newer rider, believe that other bikes are just too big or are simply drawn to Harleys, the Nightster might be the one for you. With an MSRP of $9,595.00 it's in line with its teammates. Just keep the lean angles mellow, spend plenty of time cruising the strips and ride off into the night(ster).

Source  Motorcycle.Com
